Product code: BS91_ET_PF_RID
Product description
- Available in both stainless steel and painted steel.
- Tailored solutions - Custom design for your needs.
- Reliable experience - Over 30 years of successes.
- ATEX certification - Possibility to ATEX conversion.
- Customer support - Immediate answers and solutions.
Technical specifications
| Model | BS91 ET PF RID |
| Capacity | 250 kg |
| Weight with battery | 550 kg |
| Driving | Helm |
| Grip | Mechanical (automatic) |
| Lifting | Button placed on the helm |
| Battery | 24V 200 A/h |
| Battery charger | Internal HF 24V 30A/h |
| Drive motor | 1,4 kW AC |
| Lifting motor | 2.2 kW AC |
| Travel speed | 5 km/h |
| Lifting speed | 0,16 m/s |
| Length | 925 mm |
| Width | 800 mm |
| Height | 1120 mm |
| Height | 1460/2200 mm |
| Max. lifting height | 1360 mm |
| Turning radius | 1460 mm |
| Max working pressure | 110 bar |
| Warranty (years) | 2 |
